MIDI Controllable Dual Voice Quantizer

3 CV inputs
2 voices with each 1 CV/gate output and 1 trigger input
MIDI TRS Type A input and output

• Width 16hp (80.9mm)
• Depth 35mm (including power cable)
• Standard 16 pin Eurorack power connector (cable included)
• Standard 3.5mm TS jacks
• Standard 3.5mm TRS jacks for MIDI (Type A)
• Power 100mA 12V, 15mA -12V

Trilling MC2VQ Manual

Permutational Sequencer

3 gate inputs, 1 CV output, 1 trigger output on step change.

• Width 16hp (80.9mm)
• Depth 35mm (including power cable)
• Standard 16 pin Eurorack power connector (cable included)
• Standard 3.5mm TS jacks
• Power 35mA 12V, 10mA -12V

Trilling 4051 Manual

MIDI Beat Clock Divider

MIDI TRS Type A input
18 gate outputs
Reset in and out

• Width 8hp (40.3mm)
• Depth 36mm (including power cable)
• Standard 16 pin Eurorack power connector (cable included)
• Standard 3.5mm TS jacks
• Standard 3.5mm TRS jack for MIDI (Type A)
• Power 120mA 12V

Trilling T=3ˣ·2ʸ Manual

MIDI Thru TRS Type A

1 MIDI TRS Type A in, 5 MIDI TRS Type A Thru

• Width 3hp (15mm)
• Depth 27mm (including power cable)
• Standard 10 pin Eurorack power connector (10 to 16 pin cable included)
• Standard 3.5mm TRS jacks for MIDI (Type A)
• Power < 5mA 12V
